额定容量 Rated Power (kVA)	联结组标号 Connection Symbol	电压组合Voltage Combination		空载损耗 No-load Loss (kW)	负载损耗 Load Loss (kW)	空载电流 No-load Current (％)	短路阻抗 Short-circuit impedance (％)
			高 压 H.V. (kV)	低 压 L.V. (kV)
S9-50/35	50	Yyn0	35±5%	0.4	0.21	1.1	2.8	6.5
S9-100/35	100				0.295	2.025	2.6
S9-125/35	125				0.335	2.385	2.5
S9-160/35	160				0.375	2.835	2.4
S9-200/35	200				0.45	3.35	2.2
S9-250/35	250				0.51	3.95	2
S9-315/35	315				0.61	4.8	2
S9-400/35	400				0.735	5.75	1.9
S9-500/35	500				0.865	6.95	1.9
S9-630/35	630				1.05	8.3	1.8
S9-800/35	800				1.23	9.9	1.5
S9-1000/35	1000				1.45	12.15	1.4
S9-1250/35	1250				1.75	14.7	1.2
S9-1600/35	1600				2.1	17.55	1.1
S9-800/35	800	Yd11		3.15 6.3 10	1.23	9.9	1.5
S9-1000/35	1000				1.45	12.15	1.4
S9-1250/35	1250				1.75	14.7	1.3
S9-1600/35	1600				2.1	17.55	1.2
S9-2000/35	2000				2.7	17.8	1.1
S9-2500/35	2500				3.2	20.7	1.1
S9-3150/35	3150		35±5% 38.5±5%		3.8	24.5	1	7
S9-4000/35	4000				4.55	28.8	1
S9-5000/35	5000				5.4	33.05	0.9
S9-6300/35	6300				6.55	36.9	0.9	7.5
SF9-8000/35	8000	YNd11	35 ±2×2.5% 38.5	3.15 3.3 6.3 6.6 10.5 11	9.2	40.5	0.8
SF9-10000/35	10000				10.9	47.7	0.8
SF9-12500/35	12500				12.8	56.7	0.7	8
SF9-16000/35	16000				15	69.5	0.7
SF9-20000/35	20000				18	83.7	0.7
SF9-25000/35	25000				21.3	99	0.6
SF9-31500/35	31500				25.3	118.8	0.6
